• Frame Tent

EHZ II

The Modular Frame Tent Is a Versatile Solution for Temporary Accommodation, Workspaces, or Technical Operations – Worldwide and Under All Climatic Conditions. The Basic Unit Consists of Three Sections Measuring 6.30 × 7.40 m and Can Be Flexibly Extended in 2.40 m Increments.

  • Width: 6.30 m
  • Length: 7.40 m – Unlimited
  • Modular Frame Tent for Worldwide Deployment
  • Tool-Free Setup and Dismantling
  • Suitable for All Climate Zones
  • Two-Tone Reversible Outer Tent Fabric
  • Basic Unit with 3 Sections, Extendable in 2.40 m Increments

VARIATIONS

BASIC UNIT

Width: 6.30 m / Length: 7.40 m / Ridge Height: 2.99 m Wind Load: 120 km/h / Snow Load: 50 kg/m² Supply Number: 8340-12-343-2468 Setup Time: 3–4 Persons / Approx. 1 Hour (Basic Unit with Flooring and Sun Canopy)

EXTENDABLE

UNLIMITED EXTENSION IN 2.40 M INCREMENTS

STANDARD CONFIGURATION

Anodized Aluminum Profiles with 6 Grooves, Fittings Made of Corrosion-Protected Steel

PVC-Coated Fabric, Flame-Retardant in Accordance with DIN 4102 B1, with Waterproof Welded Seams

6 Windows with Mesh Inserts, Polyglass Panels, and Blackout Covers

4 Pieces

PVC Carry Bags

No Additional Storm Guying Required

OPTIONAL EQUIPMENT

Accessories Catalog
